产品特点

◆ 采用Intel® Celeron® J6412 2.00 GHz, up to 2.60GHz, TDP 10W；

◆ 支持1路eDP1/LVDS (Wafer)；

◆ 2路 HDMI (TYPE-A): max resolution up to 1920x1080 @ 60Hz。

◆ DC12V 电源输入

应用领域

◆ 应用于物联网、工业自动化、智能交通和医疗等工业环境边缘计算，数据采集，数据分析，提供决策依据。

• CPU
  Intel® Celeron® J6412, Quad-core, clock speed 2.00 GHz, up to 2.60GHz, TDP 10W
• 内存
  1 * DDR4-2666/2933/3200MHz non-ECC SO-DIMM Slot, Up to 32GB
• 硬盘
  1 * SATA3.0 7P Connector (With 1 * SATA Power Wafer)；1 * M.2 Key-M Slot (PCIE 2x/SATA, Default PCIE 2x, Support PCIe 2x NVMe SSD, 2280)
• 显示
  1 * eDP1/LVDS (Wafer)；2* HDMI (TYPE-A):
• 网口
  2 * Intel® I225-V 2.5GBE LAN Chip (RJ45, 10/100/1000 Mbps)
• 音频
  Realtek Audio HDA Codec；1 * Line-Out + MIC 2in1 Φ3.5mm Jack ；1 * Amplifier Wafer, 3W into an 4Ω Loads
• 扩展
  1 * M.2 Key-E Slot (PCIE+USB2.0, Support WiFi +Bluetooth, 2230)；1 * M.2 Key-B Slot (PCIE/USB3.0+ PCIE/USB3.0/SATA+USB2.0；Default USB3.0, Support 5G, 2242/3042/3052)
• COM
  3 * RS232 (COM1/2/3, Wafer, Full Wires) ；2 * RS232/TTL (COM4/5, Wafer, 2 Wires)；1 * RS232/RS485/TTL (COM6, Wafer, 2 Wires)
• I/O
  3 * USB3.0 (TYPE-A, Rear IO)；3 * USB2.0 (TYPE-A, Rear IO)；3 * USB2.0 (Wafer, Internal)；8 * GPIO；1 * Front Panel Wafer；1 * CPU FAN Wafer；2 * GSPI Wafer；1 * SIM Card Connector；1 * SYS_FAN Connectors
• 供电
  1 * DC12V Power Input Connector
• 温度范围
  Operating: 0~60℃ Storage: -20~75℃
• 系统
  Windows 7/8/10, Linux, Android
• BIOS
  AMI UEFI BIOS (Watchdog Timer Supported)
• 版型
  3.5 Inch (146mm * 105mm)
